7 Meter Height Customizable Heavy Duty Warehouse Pallet Rack 4 Layers

Product Categories

LUOYANG KEDA OFFICE FURNITURE CO., LTD

Contact Now

7 Meter Height Customizable Heavy Duty Warehouse Pallet Rack 4 Layers

Name: 7 Meter Height Customizable Heavy Duty Warehouse Pallet Rack 4 Layers
Brand: Keda
Price: 1 USD

Quality 7 Meter Height Customizable Heavy Duty Warehouse Pallet Rack 4 Layers for sale

Brand Name : Keda

Model Number : KD-075

Certification : CE,SGS,BV

Place of Origin : Henan China

MOQ : 10 Set/Sets

Price : Negotiated

Supply Ability : 10000 Set/Sets per Month

Packaging Details : Carton, steel strip, wrapping film for Heavy duty selective powder coating steel warehouse pallet rack

Type : Pallet Rack, Heavy duty Rack

Material : Cold rolled steel plate Q235,

Feature : Corrosion Protection, Corrosion Protection

Use : Warehouse Rack, Warehouse Rack

Depth : 500-1200 mm

Weight Capacity : 500-4000 kg/level

Width : 1000-3000 mm

Height : 3000-7000 mm

Product name : Pallet rack

Color : Blue and orange or custom

Finish : Powder coated or galvanized

Characteristic : Stable,artistic, save space

Contact Now

7 Meter Height 4 Layers Custom Made Heavy Duty Warehouse Pallet Goods Rack

Product Description

Specification
Product Name	heavy duty warhouse pallet rack
Standard Size (Accept OEM)	Regular Outer Dimension:(Customized size is available, Extra layer is available) Width: 1800 2000 2300 2500 2700 3000 3300mm Depth: 600 800 900 1000 1100 1200 1350mm Height:1800 2000 2500 3000 4000 4500 5000 5500 6000 7000 7500 8000mm etc
Loading Capacity	1000--5000kg per layer; Or As your requirement.
Color	RAL color per (Or As your requirement.)
Main Spec.	Upright Frame	80x60, 90x70, 100x70, 120x95mm, thickness: 1.8-3.0mm
	Box Beam	80x50, 100x50, 120x50, 130x50, 140x50, 160x50mm, thickness 1.5-2.0mm
Surface treatment	Electrostatic powder coating surface
Packing List	Main Frame: Upright Frame: 2 pieces Box Beam: 6 pieces (2 pieces per layer) Sub Frame: Upright Frame :1 pieces Box Beam: 6 pieces (2 pieces per layer)
Package	corrugated paper and strapping tape

Features

1. Pallets can be located, accessed and moved individually.
2.Rapid handling almost all types of palletized goods.
3.Fully utilizes vertical space.
4.The bearing capacity per shelf of such rack may reach 5000kg.
5.Strength and rigidity prevents compression damage to goods.
6.Bottom level of pallets can be stored on the floor, lowering structure costs.
7.Durable powder coated finish, clean appearance, fire proof.
8.Height of level can be adjusted by 75mm or 76.2mm.

7 Meter Height Customizable Heavy Duty Warehouse Pallet Rack 4 Layers

PACKAGING AND SHIPING

7 Meter Height Customizable Heavy Duty Warehouse Pallet Rack 4 Layers

Package of Office used steel filing cabinet sliding full transparent glass door metal body:

1. EPE poly foam to cover each accessories inside;

2. Conner-protector is optional as your requirement;

3. Standard 5-layer brown carton for exporting;

4. Your shipping mark and logo printed on the carton;

5. Scotch tape to stick all the edges;

6. Packing belts to tie the whole carton.

FAQ

1. Q. Are you the manufacturer or trading company?

We are manufacturer with 2 factories and 1 trading company.

2. Q. What are your product structures of this Drive In Racking for Warehouse High Density Storage?

Knock-down Structure for packing.

3. Q. How many colors can I select?

You can select the color from RAL color card.

4. Q. How to pack the warehouse storage rack?

Standard export package and special package also be accepted.

5. Q. Could you provide the sample?

Yes. But the sample is not free.

6. Q. What's the payment term?

T/T, 30% in advance, 70% before shipping or L/C at sight.

7. Q. Do you have the Minimum Order Quantity?

Yes, MOQ 50pcs for each item.

8. Q. What's the delivery time?

20-30 days upon receipt of the deposit.

9. Q. What is the thickness of your steel plate?

0.4-1.2MM, depends on your choice.
